X5 pro
高端设计,2种兼容互拼箱体尺寸:500x500 / 500x1000mm
护角设计:防止意外磕碰造成灯珠损坏
隐形-5°— +5°可调弧形锁设计
升级款锁扣,可实现一人快速拆装大屏幕
箱体支持前后维护
6bit高灰度/3840Hz高刷新率,支持4K视频源.
![](https://omo-oss-image.thefastimg.com/portal-saas/pg2024022214060116706/cms/image/0428e608-7d47-4578-9aeb-11916d3ce46d.png)
![](https://omo-oss-image.thefastimg.com/portal-saas/pg2024022214060116706/cms/image/c401c9be-8a4d-49b5-b923-ad13050863f6.png)
![](https://omo-oss-image.thefastimg.com/portal-saas/pg2024022214060116706/cms/image/c0464105-f4b3-408a-b081-62c7dc14f137.png)
![](https://omo-oss-image.thefastimg.com/portal-saas/pg2024022214060116706/cms/image/6a540f9c-7ceb-409a-9ce9-7ec43c8d712f.png)
![](https://omo-oss-image.thefastimg.com/portal-saas/pg2024022214060116706/cms/image/09407904-d34f-4ba1-8c48-aa219a07e3b8.png)
![](https://omo-oss-image.thefastimg.com/portal-saas/pg2024022214060116706/cms/image/bef8f5b8-1fde-4d4a-aaa5-fcdd36cc0185.jpg)
![](https://omo-oss-image.thefastimg.com/portal-saas/pg2024022214060116706/cms/image/e990016f-f7a8-4b39-b40f-62ff0ad425aa.jpg)
![](https://omo-oss-image.thefastimg.com/portal-saas/pg2024022214060116706/cms/image/c76c2383-56b2-4432-9dc9-ea6e61d15e0a.jpg)
高端设计
2种兼容互拼箱体尺寸:500x500 / 500x1000mm.
护角设计
防止意外磕碰造成灯珠损坏
可调弧形锁设计
隐形-5°— +5
升级款锁扣
可实现一人快速拆装大屏幕
箱体支持前后维护
箱体支持前后维护
6bit高灰度/3840Hz高刷新率
支持4K视频源.
产品参数
产品名称 | X5 PRO 系列 | ||||||||
应用 | 室内 | 户外 | |||||||
Pixel Pitch(mm) | 1.9 | 2.6 | 2.976 | 3.91 | 2.6 | 2.976 | 3.91 | ||
LED Lamp Type | SMD1515 | SMD1515 | SMD2020 | SMD2020 | SMD1415 | SMD1415 | SMD1921 | ||
Pixel Density | 262,144dots/㎡ | 147,456dots/㎡ | 112,896dots/㎡ | 65,536dots/㎡ | 147,456dots/㎡ | 112,896dots/㎡ | 65,536dots/㎡ | ||
Scan Frequncy | 1/32 | 1/32 | 1/28 | 1/16 | 1/32 | 1/28 | 1/16 | ||
Module Size | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 | ||
Cabinet Size | 500*500 | 500*500 | 500*500 | 500*500 | 500*500 | 500*500 | 500*500 | ||
Cabinet Material | 压铸铝 | ||||||||
Cabinet weight | 6.8kg | 6.8kg | 6.8kg | 6.8kg | 7.3KG | 7.3KG | 7.3KG | ||
Viewing Angle | H:160°/ V:160° | H:160°/ V:160° | H:160°/ V:160° | H:160°/ V:160° | H:160°/ V:160° | H:160°/ V:160° | H:160°/ V:160° | ||
Grey Scale (bits) | 16Bit | 16Bit | 16Bit | 16Bit | 16Bit | 16Bit | 16Bit | ||
Frame Rate(HZ) | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | ||
Refresh Rate(HZ) | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz | ||
Brightness(cd) | 800-1000 | ≥5500 | |||||||
Input Voltage(V) | AC 100~240V | AC 100~240V | AC 100~240V | AC 100~240V | AC 100~240V | AC 100~240V | AC 100~240V | ||
Ave. Power Consumption(W/m2) | 160 | 160 | 160 | 160 | 220 | 220 | 220 | ||
Max Power Consumption(W/m2) | 560 | 560 | 560 | 560 | 680 | 680 | 680 | ||
IP Grade | IP30 | IP30 | IP30 | IP30 | IP65 | IP65 | IP65 | ||
Control method | 同步/异步/4G/WIFI | 同步/异步/4G/WIFI | |||||||
Maintenance | 前/后维护 | 前/后维护 | |||||||
Working humidity | 10~85% RH | 10~95% RH | |||||||
Working Temperature | -30 - 60 ℃ | -30 - 60 ℃ | |||||||
Life span(H) | 100,000 | 100,000 | |||||||
Certificate | CCC/RoHS CE /EMC IFCC | CCC/RoHS CE /EMC IFCC |
